Copper Patch Cords · CAT.6A

CAT.6A Ultra Flexible U/UTP 32AWG Slim Patch Cable

32AWG ultra-flexible slim patch cable with only 2.8 mm OD and a halogen-free TPE jacket. The bendable flex boot turns to any angle, saving rack space and improving airflow in high-density patching — far more flexible than a standard LSZH cable.

CAT.6A Ultra Flexible U/UTP 32AWG Slim Patch Cable
Main view Detail 1 Detail 2 Detail 3

Specifications

Product No. 160914172

U/UTP · 32AWG · Ø2.8 mm

ConstructionU/UTP
CategoryCAT.6A
Conductor32AWG bare copper
Cable OD2.8mm
Jacket MaterialTPE | PVC | LSZH
Boot TypeFlex boot All-Angles Bendable
Length Range0.3m –15m
ComplianceRoHS, REACH, CE, CPR, ISO 9001, ISO 14001, RCM, UKCA, UL 444
Request Quote ← Back to CAT.6A Products

Applications

🔌Data Centers
🔌Structured Cabling
🔌AI Computing
🔌High-Density Patching
🔌Hotels & Offices

Key Features

1.The unique bendable flex boot meets various angles in all possible applications
2.The TPE coated 32AWG cable features only 2.8mm in diameter — easy to route and saving valuable space in high density
3.It easily copes with narrow spaces, prevents the cable from bending and increases the lifespan
4.Halogen-free TPE jacket is extremely flexible compared to a standard LSZH jacket

Customization Options

🔧
Any Length

Any length, connector and boot option to your requirement.

🔧
Jacket & Printing

TPE, PVC or LSZH jacket with colour printing available.

🔧
Connector & Boot

Made to your drawing or specification.
